Product Details:
|
| Type: | P3.33 Led Module | Luminous Intensity: | 860cd / M² |
|---|---|---|---|
| Size: | 320 X 160mm | Led Type: | RGB 3IN1 2121 |
| Scanning Method: | 26S | Control Mode: | Synchronous Control Or Asynchronous Control |
| High Light: | P3.33mm led display module,led sign modules 3.33mm,LONGDA outdoor led module |
||
Led Screen Module P3.33 Outdoor Fixed Led Video Wall Waterproof IP65
Advantages :
1 . LED advertisement P3.33 led display with strong visual impact , large size , dynamic effect ;
2 . Sound and picture integration can comprehensively stimulate the audience ' s sense and
effectively convey information to guide consumption ;
3 . Long release period outdoor LED advertisement can be played around the clock , waterproof .
Specifications :
| Pixel Pitch | 3.33mm LED MODULE | ||||
| Module Resolution | W96 * H48 dots | ||||
| Module Size | 320 * 160mm | ||||
| Led Packing | 2121 | ||||
| IP Rate |
65 |
||||
| LED composition | 1R1G1B | ||||
| Brightness | 860cd / m² | ||||
| Colors | 16.7 trillion | ||||
| Brightness Control | Software 256 level adjustable | ||||
| Gray Level | 16 | ||||
| View Distance | 2～100m | ||||
| Refresh Rate | 1920hz ~ 3840Hz | ||||
| Drive Mode | 1 / 26s | ||||
| Life Span | 100000h | ||||
| MTBF | 1000h | ||||
| Frame Frequency | ≥ 60Hz | ||||
| Certification | CE / ROHS / FCC / CCC / ISO9001 / ISO14001 | ||||
| Operation Temperature | - 20 ℃ ～ + 45 ℃ | ||||
| Operation Humidity | 10 % ～ 95 % |
Applications :
Led display outdoor P3.33 is suitable for a variety of occasions , advertising publish , retail store , KTV ,
self - service business , exhibition hall , wayfinding , airport , subway elevator , education , bar , club ,
shopping mall , entertainment , shows , welcome display , runway shows , amusement park , theme park .
FAQ :
1 . Are you a manufacturer or trading company ?
We are a Professional OEM / ODM manufacturer which has specialized in led display industry for more than 12 years .
2 . What is your MOQ ?
Any quantity is acceptable for your order . And the price is negotiable for large quantity .
3 . When will you make the delivery ?
We can make the delivery within 3 - 5 working days for the led modules and 10 - 30 days for the led display with cabinet
according to the size and quantities of your order .
4 . How long is the warranty ?
The standard warranty is 1 or 2 years . It could be longer upon request .
5 . Do you provide any free spare parts in each order ?
Yes , a certain amount of spare parts will be provided for free , spare parts including module , power cable ,
signal cable , LED lamp , IC , mask , power supply , receiving card , etc .
6 . How to install led display for rental event ?
You have two installation ways to choose :
a . hanging with hanging beam
b . stand on floor by truss .
7 . How to choose the control way by computer or phone ?
Synchronous by computer : usually for indoor fixed and all rental event .
Asynchronous by phone or ipad : widely used for outdoor fixed advertising .
8 . How about your packing ?
Carton / Plywood case / Flightcase .
9 . Do you test all your goods before delivery ?
Yes , we have 100 % test before delivery .
10 . What is your terms delivery ?
EXW , FOB , CFR , CIF , DDP , DDU ...
11 . What is your payment term ?
T / T , L / C , MoneyGram , Western Union , etc .
