Product Details:
|
| Pixel Pitch: | 1.875mm | Usage: | Indoor |
|---|---|---|---|
| Screen Dimension: | 600mm * 337.5mm | Tube Chip Color: | Full Color |
| Module Size: | 300 X 168.75mm | Led Chip: | 1515 |
| High Light: | high precision LONGDA LED display,LONGDA LED display durable,small pitch led display 2160P |
||
Led Stage Backdrop Screen LED Video Wall Display P1.875 Small Pixel Pitch Module Screen
Advantages :
1 . Fine pitch Led display delivering true - to - life images and videos with high precision pixel pitches ,
bringing a great viewing experience to the audience at a close viewing distance ;
2 . By providing extraordinary image quality with precise colors , fine pitch Led display creates remarkable
visual experiences that keep constant over time ;
3 . 16:9 Golden division ratio : it can be point to point spliced to the led screen of standard 720P , 1080P ,
2160P , 3840P , etc .
Specification :
|
OPTICAL |
Pixel Pitch |
mm |
1.875mm |
|
LED No. Per Pixel |
pcs/pixel |
1 |
|
|
Brightness(Adjustment) |
cd/m² |
600~800 |
|
|
LED Encapsulation |
- |
SMD 1515 |
|
|
Module Resolution(W*H) |
pixels |
|
|
|
Cabinet Resolution(W*H) |
dots |
256*256 |
|
|
Pixel Density |
dots/sqm |
284,444 |
|
|
Viewing Angle(H/V) |
degree |
H160/V160 |
|
|
Color Depth/Number |
bit |
16,384 |
|
|
Grey Scale |
- |
14bit |
|
|
ELECTRICAL |
Frame Frequency |
Hz/s |
50/60 |
|
Refresh Rate |
Hz |
2880 |
|
|
Contrast Ratio |
- |
5000:1 |
|
|
Max Power Consumption |
W/m² |
660 |
|
|
Ave Power Consumption |
W/m² |
230 |
|
|
Working Voltage |
AC |
AC110V~ 220V |
|
|
Drive Voltage |
DC |
15V |
|
|
Color Temperature |
- |
|
|
|
Working Temperature |
ºC |
-0ºC-40ºC |
|
|
Humidity |
- |
10%-85%RH |
|
|
Driving Method |
- |
1/32scan |
|
|
MECHANICAL |
Frame Material |
- |
Die-casting aluminum |
|
Module Size |
mm |
|
|
|
Net Weight |
kg/pcs |
6 |
|
|
Weight Per Tile |
lbs |
13.24 |
|
|
Cabinet Size |
mm |
480*480*67 |
|
|
IP Rating |
- |
IP30 |
|
|
Lifetime |
hours |
100,000 |
|
|
Service Access |
- |
front/rear |
|
|
Application |
- |
Indoor |
Led Display Service for customers :
1 . We provide pre - sale service in technical consultation , for example , recommending and designing solutions
as pre the customers request , which help lower the risk of customers` investing .
2 . In the process of production , gloshine follows up the tightly and accept the supervision from the clients .
Necessary trainings are also provided to the customers .
3 . For the after - sale service , Noveled takes the great responsibility to collect customer ' s feedback ,
inspection and maintains products periodically to ensure solving problems timely .
