P1.875 Smart LED Poster Display Screen 480 X 480mm 80W / M2 Diecasting Aluminum

P1.875 Smart LED Poster Display Screen 480 X 480mm 80W / M2 Diecasting Aluminum
P1.875 Smart LED Poster Display Screen 480 X 480mm 80W / M2 Diecasting Aluminum
P1.875 Smart LED Poster Display Screen 480 X 480mm 80W / M2 Diecasting Aluminum P1.875 Smart LED Poster Display Screen 480 X 480mm 80W / M2 Diecasting Aluminum P1.875 Smart LED Poster Display Screen 480 X 480mm 80W / M2 Diecasting Aluminum P1.875 Smart LED Poster Display Screen 480 X 480mm 80W / M2 Diecasting Aluminum P1.875 Smart LED Poster Display Screen 480 X 480mm 80W / M2 Diecasting Aluminum

Large Image :  P1.875 Smart LED Poster Display Screen 480 X 480mm 80W / M2 Diecasting Aluminum

Product Details:
Place of Origin: Shenzhen , China
Brand Name: Longda Led
Certification: CCC , CE , ROHS , FCC , ISO9001 , ISO14001
Model Number: P1.875
Payment & Shipping Terms:
Minimum Order Quantity: 1 Sqm
Price: Usd799 ~ Usd1099 / Sqm ( price is negotiable )
Packaging Details: Plywood case / flightcase
Delivery Time: 15 - 18 days
Payment Terms: L / C , T / T , Western Union , MoneyGram
Supply Ability: 5000sqm per month

P1.875 Smart LED Poster Display Screen 480 X 480mm 80W / M2 Diecasting Aluminum

Description
Led Lamp: SMD1515 Cabinet Size: 480 * 480mm
Cabinet Material: Die - Casting Aluminum PCB Color: Black
Usage: Indoor Full Color Led Display Screen Dimension: Customized Size
High Light:

P1.875 smart led poster display

,

led poster display 80W/ m2

,

poster led screen 480x480mm

Small Pixle Led Display P1.875 480 X 480mm Cabinet Led Poster Display Indoor Usage





Product Introduction :



1 . High definition and high resolution , show a wonderful visual performance ;

2 . Good quality and very competitive price in the market , because we are the manufacturer ;

3 . High resolution could guarantee superior performance even with small screen size .



Specifications :



Indoor P1.875 Full Color LED Screen

Part I Technicial Parameters

Led Module Specification

NO.

Item

Specification

1

Pixel Pitch

1.875mm

2

Module Resolution

W128×H64dots

W128×H128dots

W128×H128dots

3

Module Size

240*120mm

240*240mm

240*120mm(soft)

4

Led Packing

1515

5

IP Rate

43

6

IC

LS9929+LS9379

2053

2053

2053

5124

7

LED composition

1R1G1B

Cabinet Specification

1

Cabinet Size

480*480mm

Magnet Splicing

2

Module Qty

W2X H4 =8PCS

W2× H2=4PCS

/

3

Physical Resolution

W256×H256dots

W256×H256dots

/

4

Power Consumption(MAX.)

200W/m2

650W/m2

5

Power Consumption(AVE.)

80W/m2

300W/m2

6

Cabinet Material

Die-casting Aluminum

Magnet Splicing

7

Physical Density

284444 dots/m2

8

Net Weight

5Kg

/

Screen Specification

1

Brightness

670cd/m2

600cd/m2

650cd/m2

600cd/m2

700cd/m2

2

Colors

16.7 trillion

3

Brightness Control

Software 256 level adjustable

4

Gray Level

14

5

View Distance

≥1.8m~15m

1.3m~12m

6

Refresh Rate

≥3840Hz

≥1920Hz

≥2800Hz

≥2800Hz

≥1920Hz

7

Drive Mode

1/64s

1/32s

1/32s

1/64s

1/32s

8

Life Span

100,000h

9

MTBF

1000h

10

Control mode

Synchronous control or Asynchronous control

11

Frame Frequency

≥60Hz

12

Certification

CE/ROHS/FCC/CCC/ISO9001/ISO14001

13

Operation Temperature

-20℃ ~ +45℃

14

Operation Humidity

10%~95%


P1.875 Smart LED Poster Display Screen 480 X 480mm 80W / M2 Diecasting Aluminum 0





Fast Front Maintenance :



P1.875 Smart LED Poster Display Screen 480 X 480mm 80W / M2 Diecasting Aluminum 1





FAQ :



1. Strict quality control :
The quality of our display is excellent . We use the materials of high quality suppliers in the world ,

strictly control the production process , and pass the multiple quality inspection to ensure that everyproduct is qualified .

2. Quality guarantee:
All our LED display screens is more than 100,000 hours life span

3. Long warranty:
Two - year warranty, any quality problem during warranty time will be handled .

4. Prompt &Professional service:
Any inquires will be replied within 24/7 hours and you'll get helpful suggestions from us.




Your questions :


Q1:LED display models are generally expressed in PX, such as P2 P3 P4.....P8, P10, what does this mean?
A: P1.25, P2, P3 P4.....P8,P10 means that the pixel pitch is 1.25mm, 2mm, 3mm 4mm....10mm,

which determines resolution of a display .Pixel pitch is smaller, led display resolution is higher.

Q2:What pixel pitch should I choose on my display?

A:Using the PX screen, it is determined mainly by the viewing distance, the size of the

display screen, thedesired effect and the customer budget.

Q3: To order a display ,What kind of information do I have to offer you?
A:You should provide width/height of the display, the main use, the viewing distance,

the scene photos, special requirements,then I can provide you with a detailed list of quotations.

Q4:How to install?
A:Free of charge to provide detailed steel structure drawings and installation guidance and wiring diagram,

free remote debugging. We can also send our engineers to the site to guide the installation if needed.

Q5:What about the lead time?
A:Orders less than 50 square meter display, lead time is 15 working days.

Q6:Can I order a sample?
A:Yes, your sample orders are welcome, after checking our quality and service,

we are confident that you will come back for your future orders.
