IP65 1R1G1B Transparent Video Wall Advertising 500*125mm Window Display

IP65 1R1G1B Transparent Video Wall Advertising 500*125mm Window Display
IP65 1R1G1B Transparent Video Wall Advertising 500*125mm Window Display IP65 1R1G1B Transparent Video Wall Advertising 500*125mm Window Display IP65 1R1G1B Transparent Video Wall Advertising 500*125mm Window Display IP65 1R1G1B Transparent Video Wall Advertising 500*125mm Window Display

Large Image :  IP65 1R1G1B Transparent Video Wall Advertising 500*125mm Window Display

Product Details:
Place of Origin: ShenZhen
Brand Name: Longda Led
Certification: CCC , CE , ROHS , FCC , ISO9001 , ISO14001
Model Number: T - P3.91
Payment & Shipping Terms:
Minimum Order Quantity: 1 Sqm
Price: Usd799 ~ Usd1099 / Sqm ( price is negotiable )
Packaging Details: Flight case packing or Plywood case packing
Delivery Time: 15 - 18 days
Payment Terms: L / C , T / T , Western Union , MoneyGram
Supply Ability: 5000sqm per month

IP65 1R1G1B Transparent Video Wall Advertising 500*125mm Window Display

Description
MTBF: 1000h IP Rate: 43 / 65
Led Packing: 1921 Pixel Pitch: P3.91mm
Cabinet Size: 1000 * 500mm Physical Density: 32873 Dots / M²
High Light:

1R1G1B transparent video wall

,

IP65 transparent led window display

,

video wall advertising 500*125mm

Transparent Glass Led Screen Colorful Glass Window Curtain Indoor Advertising Video Wall P3.91




Product Introduction :

1 . No steel frame structure , saving a lot of installation and maintenance costs ;
2 . Directly fixed on the glass curtain wall , without any steel structure , save a lot of cost ;
3 . The unique display effect because the display background is transparent , can make the advertising picture
give people the feeling of suspension on the glass curtain wall , with good advertising effect and artistic effect ;
4 . Easy and fast maintenance of indoor maintenance , both fast and safe , save manpower and material resources .




Specifications :



P3.9-7.8 Full Color LED Transparent Screen

Part I Technicial Parameters

Led Module Specification

NO.

Item

Specification

1

Pixel Pitch

3.9-7.8mm

2

Module Resolution

W128×H16dots

3

Module Size

500*125mm

4

Led Packing

1921

1921

2020

5

IP Rate

43

6

IC

2038

7

LED composition

1R1G1B

Cabinet Specification

1

Cabinet Size

1000*500mm

2

Module Qty

W2X H 4 =8PCS

3

Physical Resolution

W256×H64dots

4

Power Consumption(MAX.)

800 W/m2

600W/m2

400W/m2

5

Power Consumption(AVE.)

220 W/m2

200W/m2

180W/m2

6

Cabinet Material

Die-casting Aluminum

7

Physical Density

32873 dots/m2

8

Net Weight

6Kg

Screen Specification

1

Brightness

5000cd/m2

3500cd/m2

1000cd/m2

2

Colors

281 trillion

3

Brightness Control

Software 256 level adjustable

4

Gray Level

14

5

View Distance

5~12m

6

Refresh Rate

≥3840Hz

7

Drive Mode

1/8s

1/16s

8

Life Span

100,000h

9

MTBF

1000h

10

Control mode

Synchronous control or Asynchronous control

11

Frame Frequency

≥60Hz

12

Certification

CE/ROHS/FCC/CCC/ISO9001/ISO14001

13

Operation Temperature

-20℃ ~ +45℃

14

Operation Humidity

10%~95%


IP65 1R1G1B Transparent Video Wall Advertising 500*125mm Window Display 0




FAQ:

1. Strict quality control :
The quality of our display is excellent . We use the materials of high quality suppliers in the world ,
strictly control the production process , and pass the multiple quality inspection to ensure that everyproduct

is qualified .


2. Quality guarantee:
All our LED display screens is more than 100,000 hours life span .



3. Long warranty:
Two - year warranty, any quality problem during warranty time will be handled .



4. Prompt &Professional service:
Any inquires will be replied within 24/7 hours and you'll get helpful suggestions from us.



Your questions:


Q1:LED display models are generally expressed in PX, such as P2 P3 P4.....P8, P10, what does this mean?
A: P1.25, P2, P3 P4.....P8,P10 means that the pixel pitch is 1.25mm, 2mm, 3mm 4mm....10mm,
which determines resolution of a display .Pixel pitch is smaller, led display resolution is higher.



Q2:What pixel pitch should I choose on my display?
A:Using the PX screen, it is determined mainly by the viewing distance, the size of the
display screen, thedesired effect and the customer budget.



Q3: To order a display ,What kind of information do I have to offer you?
A:You should provide width/height of the display, the main use, the viewing distance,

the scene photos, special requirements,then I can provide you with a detailed list of quotations.



Q4:How to install?
A:Free of charge to provide detailed steel structure drawings and installation guidance and wiring diagram,

free remote debugging. We can also send our engineers to the site to guide the installation if needed.



Q5:What about the lead time?
A:Orders less than 50 square meter display, lead time is 15 working days.



Q6:Can I order a sample?
A:Yes, your sample orders are welcome, after checking our quality and service,

we are confident that you will come back for your future orders.
