Product Details:
|
| Product Name: | Outdoor P5 Led Display Screen | LED Composition: | 1R1G1B |
|---|---|---|---|
| Weight: | 28Kg | Working Temperature: | - 40 ℃ ~ 60 ℃ |
| Working Humidty: | 10 % ~ 90 % | Frame Frequency: | 60HZ |
| High Light: | P5 curved led display outdoor,1R1G1B curved led display outdoor,SMD3528 full color led display |
||
Full Color P5 1R1G1B Outdoor Curved LED Display SMD3528
Advantages
Curved full color P5 led display screen is always a hot-selling model for outdoor use,
high brightness, large viewing angle, easy to maintenance, waterproof metal frame,
synchronous& asynchronous system, good heat dissipation.
Specifications
|
Item |
Specification |
|||||
|
Pixel Pitch |
5mm |
|||||
|
Module Resolution |
W64×H32dots |
W64×H32dots |
W64*H32dots |
W32×H32dots |
||
|
Module Size |
320*160mm(soft) |
320*160mm |
320*160mm |
160*160mm |
||
|
Led Packing |
2121 |
Nationstar2121 |
3528 |
3528 |
||
|
IP Rate |
43 |
65 |
||||
|
IC |
5124 |
|||||
|
LED composition |
1R1G1B |
|||||
|
Cabinet Size |
640*640mm |
|||||
|
Module Qty |
W2X H4=8PCS |
W2X H4=8PCS |
W2X H4=8PCS |
|
||
|
Physical Resolution |
W128×H128dots |
|||||
|
Power Consumption(MAX.) |
200W/m2 |
300W/m2 |
||||
|
Power Consumption(AVE.) |
110W/m2 |
170W/m2 |
||||
|
Cabinet Material |
Die-casting Aluminum |
|||||
|
Physical Density |
40000 dots/m2 |
|||||
|
Net Weight |
6.8Kg |
7Kg |
7.2Kg |
|||
How to make a curved led display?
1. Message or call us, we will 24 hours standby and reply you;
2. Share with us more details of your project like radium, diameter, height, installation method and so on,
the more you share with us, the sooner we quote you;
3. We design the size and provide complete proposal to you within 24 hours;
4. We talk more details about the size, installation, price;
5. You placed order and we provide CAD drawing for your reference.
