Product Details:
|
| Pixel Pitch: | 1.25mm | Usage: | Indoor |
|---|---|---|---|
| Screen Dimension: | 600mm*337.5mm | Led Chip: | 1010 |
| Display Function: | Video, Animation, Graphics | Brightness: | 300-600nits |
| High Light: | DC5V small pixel pitch led screen,4k led video wall 600mm*337.5mm,P1.25mm 4k led panel display |
||
Small Pixel Pitch Led Display HD High Resolution P1.25 4K High Quality Display
Advantages
1.Ultra high definition
It delivers a truly amazing picture with extraordinary pixels producing an image that is HD quality in an LED screen .
2.High strength Aluminum alloy material
The integral die-casting aluminum molding workmanship has provided with excellent flatness of the cabinet
3.Front serviceable led screen for better experience
The front serviceable ultra HD led screen cabinet has fully described the strength of its light weight,met the needs of small space or where the needs of the cabinet thickness is needed, enhanced the vision of the space as well as its visionary effect.
it allows for easy maintenance, saving time and labor site.
Specifications
|
OPTICAL |
Pixel Pitch |
mm |
1.25mm |
|
LED No. Per Pixel |
pcs/pixel |
1 |
|
|
Brightness(Adjustment) |
cd/m² |
600 |
|
|
Pixel Configuration |
- |
SMD1010 |
|
|
Module Resolution(W*H) |
pixels |
160*135 |
|
|
Cabinet Resolution(W*H) |
dots |
480*270 |
|
|
Pixel Density |
dots/sqm |
640,000 |
|
|
Viewing Angle(H/V) |
degree |
H160/V160 |
|
|
Color Depth/Number |
bit |
16bit |
|
|
Grey Scale |
- |
65,536 |
|
|
ELECTRICAL |
Frame Frequency |
Hz/s |
50/60 |
|
Refresh Rate |
Hz |
≥3,840 |
|
|
Contrast Ratio |
- |
5000:1 |
|
|
Max Power Consumption |
W/m² |
800 |
|
|
Ave Power Consumption |
W/m² |
250 |
|
|
Working Voltage |
AC |
AC90~264V |
|
|
Drive Voltage |
DC |
5V |
|
|
Working/Storage Temperature |
ºC |
-20ºC - 60ºC |
|
|
Humidity |
- |
10%-85%RH |
|
|
Driving Method |
- |
1/27scan |
|
|
MECHANICAL |
Frame Material |
- |
Die-casting aluminum |
|
Module Size |
mm |
300 * 168.75 |
|
|
Net Weight |
kg/pcs |
6kg |
|
|
Weight Per Tile |
lbs |
17.21 |
|
|
Cabinet Size |
mm |
600*337.5*55 |
|
|
IP Rating |
- |
IP30 |
|
|
Lifetime |
hours |
100,000 |
|
|
Service Access |
- |
front |
|
|
Application |
- |
Indoor |
Packaging & Shipping
Packing: Anti-shaking wooden cabinet / Air flight case/strong carton
Shipping port: Shenzhen , China
Shipping way:Air ; Express ; Ocean ; Land Transportation
Delivery time: 15 - 18 working days after confirm receipt payment in advance
Long working life: In the Maintenance period , free of all maintenance charge
After maintenance period only charge the material costs fees
