Product Details:
|
| Model: | 10mm | Net Weight: | 17Kg |
|---|---|---|---|
| View Distance: | 6 ～ 50m | Life Span: | 100000h |
| Brightness: | 7000CD / M² | Colors: | 16.7 Trillion |
| High Light: | SMD3535 Led Stage Backdrop Screen,waterproof p10 led display,p10 outdoor led display LINSN |
||
Led stage backdrop screen P10 Outdoor Protection Perimeter LED Display for Sports Soccer Field
Advantages :
1 . Made with iron material cabinet , waterproof IP65 and durable ;
2. Easy and quick to install and dismantle with any tools ;
3 . Back installation for drivers , benefical to maintenance ;
4 . Seamless splice , can be adjustable mildly ;
6 . High brightness , high refresh rate , good performance .
Product descripition :
|
NO.: |
Product name |
P10 outdoor led display |
|||
|
1 |
Pixel Pitch(mm) |
10mm |
|||
|
2 |
Pixel configuration |
1R1G1B / SMD3535 White lamp |
|||
|
3 |
Pixel density |
10000dots / m² |
|||
|
4 |
Brightness |
7000cd / m² |
|||
|
5 |
Module size(W*H) |
320mm × 160mm |
|||
|
6 |
Module Resolution (W*H) |
32 dots x 16dots |
|||
|
7 |
Module weight |
500g |
|||
|
8 |
Cabinet size (W*H) |
1024mm × 1024mm / 640mm x 960mm |
|||
|
9 |
Drive IC |
Constant current energy saving IC |
|||
|
10 |
Drive mode |
1 / 2s |
|||
|
11 |
Viewing Angle(V/H) |
140 ºC |
|||
|
12 |
Grey Scale |
14 |
|||
|
13 |
Life time |
> 100000 Hours (50%) |
|||
|
14 |
MTBF |
> 50000 Hours |
|||
|
15 |
Operating Voltage |
AC110V/220V±10% |
|||
|
17 |
Screen Power Consumption |
Max: 1000w/m² ; Average: 600w/m² |
|||
|
18 |
Input Power Frequency |
60Hz |
|||
|
19 |
Operating temperature |
- 30 - 60ºC |
|||
|
20 |
Humidity |
10% - 95% |
|||
|
21 |
Refresh Rate |
≥ 1920HZ |
|||
|
22 |
Control Method |
Synchronized with computer monitor |
|||
|
23 |
Color Temperature |
6500K-9500K |
|||
|
24 |
LED control system |
LINSN,Nova-star,Colorlight is selectable |
|||
|
25 |
Control Distance |
100 m (no repeating); Optical fiber transmission: 500m- 15km |
|||
|
26 |
Accepting signal with video processor |
PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI |
|||
|
27 |
Systems Operating Platform |
Windows 7 / windows 8 / 8.1 / windows 10 |
|||
FAQ :
Q1: Can I have a order sample for Led display?
A: Yes, welcome sample order to check and test quality, Maxed samples are acceptable.
Q2: What about the lead time ?
A: Sample needs one week, mass production time needs 2-3 weeks for order quantity more than.
Q3: Do you have any MOQ limit for Led display order ?
A: Low MOQ, 1pc sample for checking is available.
Q4: How do you ship the goods and how long does it take to arrive ?
A: We usually ship by DHL, UPS, FedEx or TNT, It usually take 3-5days to arrive , Airline and Sea shipping also optional.
Q5: How to proceed an order for Led display ?
A: Firstly, Let us know your requirement or application.
Secondly we quote you according to your requirement or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly.we arrange the production.
Q6: Is it ok to print my logo on the Led display product ?
A: Yes, please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer the guarantee for the products ?
A: Yes, we offer 2-5 years warranty to our products.
Q8: How do deal with the faulty ?
A: Firstly, our products are produced in strict quality control system and the defective rate will be less than 0.2%.
Secondly, during the guarantee period, we will send you spare parts with new order for small quantity.
For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation .
