Product Details:
|
Pixel: | P3.91 | Module Size: | 250 X 250mm |
---|---|---|---|
Scan: | 16s | Cabinet Size: | 500 * 500mm / 500x1000mm |
Brightness: | ≥ 5000nits | Refresh Rate: | 3840hz |
High Light: | 3.91mm Led Stage Backdrop Screen,P3.91 billboard led screen,backdrop led screen 65536 dots |
Led Stage Backdrop Screen SMD P3.91 Indoor LED Stage Backdrop LED Stage Display Screen
Advantages :
1 ) It is extremely easy to calculate the area of LED screen because it is consist of 500 * 500mm cabinet
2 ) 16 bit color , 65536 gray scale , refresh rate over 3840HZ/S so the video or images on the LED screen
are very vivid and fresh. People who see it will get shocked by this amazing viewing experience
3 ) The appearance is very elegant, it looks very high end. Quality is very stable
4 ) It is die-casting aluminum cabinet, very strong and precision is very high , tolerance can be controlled
in 0.1mm so the surface is very smooth, almost no gap between cabinets
5 ) The side locks is spring locks, this is unique among all die-casting aluminum cabinets , especially popular
in European market and North American market
6 ) With power and signal connectors , Neutrik or Seetronic brand, very easy to install and dismantle
7 ) High contrast rate up to 5000 : 1 by using black LED
Technical parameters :
P3.91 Rental Stage Video LED Display Screen For Outdoor |
|||||||
Item |
Technical Parameters |
||||||
LED Parameters |
|||||||
Item Name |
LED Type |
Brightness |
Wave Length |
H/V Visual Angle |
|||
Red LED |
SMD1921 |
540-702mcd |
620-625nm |
160º/160º |
|||
Green LED |
SMD1921 |
1200-1300mcd |
519-522nm |
160º/160º |
|||
Blue LED |
SMD1921 |
200-260mcd |
462-465nm |
160º/160º |
|||
Pixel Pitch |
3.91mm |
||||||
Pixel Configuration |
1R1G1B |
||||||
Module Resolution |
64 x 64 pixels |
||||||
Module Pixles |
4096 pixels |
||||||
Module Size |
250mm X 250mm |
||||||
Cabinet Size(W X H X D) |
500mm x 1000mm x 80mm |
||||||
Cabinet Resolution(dot) |
128 x 256 pixels |
||||||
Cabinet Materials |
Die Casting Aluminum Cabinet for rental purpose |
||||||
Packaging |
Fly case |
||||||
Fly Case Size |
105*65*65CM ( one case for six cabinets )/ 85kg |
||||||
Driving Method |
1/16 scan |
||||||
Control Mode |
Synchronous display with control PC by DVI |
||||||
Certificate |
CE, ROHS, FCC |
FAQ :
1:What is the warranty of your led display?
A:We offer 5 years warranty.and more than 100000 hours screen life span
2:what is your payment term?How long it takes to delivery?
A:We usually accapt the T/T or L/C.both of them will at least 30% deposit in advance,and the rest of
70% will paid before delivery.The lead time is usually 20 day
3:What is your pre-sale and post-sale service?
A:For pre-sale service,we have professional sales team and technical team,who are willing to answer
your question within 24 hours.
For post-sale service,we will instruct you how toinstallation,how to use,how to change the broken
moudles,and we can also send the technicals to your country,in general,our led display will not have a
big problem,you can rest assured to buy.
