Durable HD SMD1515 Curtain Stage Background Led Screen 1.8m LED Panel

Certification
China Shenzhen Longdaled Co.,Ltd certification
China Shenzhen Longdaled Co.,Ltd certification
I'm Online Chat Now

Durable HD SMD1515 Curtain Stage Background Led Screen 1.8m LED Panel

Durable HD SMD1515 Curtain Stage Background Led Screen 1.8m LED Panel
Durable HD SMD1515 Curtain Stage Background Led Screen 1.8m LED Panel Durable HD SMD1515 Curtain Stage Background Led Screen 1.8m LED Panel Durable HD SMD1515 Curtain Stage Background Led Screen 1.8m LED Panel Durable HD SMD1515 Curtain Stage Background Led Screen 1.8m LED Panel Durable HD SMD1515 Curtain Stage Background Led Screen 1.8m LED Panel

Large Image :  Durable HD SMD1515 Curtain Stage Background Led Screen 1.8m LED Panel

Product Details:
Place of Origin: Shenzhen , China
Brand Name: Longdaled
Certification: CE / RoHs / FCC / CCC / ISO9001 / ISO14001
Model Number: Small Pixel - P1.8
Payment & Shipping Terms:
Minimum Order Quantity: 1 Sqm
Price: Price is Negotiable
Packaging Details: Plywood case / Flight case
Delivery Time: 15 - 18 days
Payment Terms: T / T
Supply Ability: 1000sqm per month

Durable HD SMD1515 Curtain Stage Background Led Screen 1.8m LED Panel

Description
Model: 1.8mm Cabinet Size: 600mm*337.5mm
Refresh Rate: 3840Hz Brightness: 300-800nits
Resolution: 160*90 Scan: 1/43
Cabinet Material: Die - Casting Aluminum Warranty: 3 Years
Highlight:

hd led panel 1000cd/ m2

,

stage background led screen 1.8m

,

led stage curtain screen SMD1515

Led Stage Backdrop Screen Slim Rental LED Display P1.8 Indoor LED Video Wall Screen



Introductions :


1 . Ultra HD : up 309136 pixels per square meters , like as HD TV screen with full color ;
2 . Ultra slim cabinet : the thickness is only 65mm , with fashion configuration design ;
3 . High strength : made with high quality die - casting aluminum cabinet , enhance the heat dissipation ,
and extend the cabinet's working life .


Durable HD SMD1515 Curtain Stage Background Led Screen 1.8m LED Panel


Specifications :


Model No

SP0.9

SP1.2

SP1.5

SP1.8

Pixel Pitch

0.9375mm

1.25mm

1.56mm

1.875mm

LED

Mini LED

SMD1010

SMD1010

SMD1515

Module Size(mm)

300*168.75

300*168.75

300*168.75

300*168.75

Module Resolution(dots/)

320 * 180

240 * 135

192 * 108

160 * 90

Pixel Density

1,137,777dots/m²

640,000dots/m²

409,600dots/m²

284,444dots/m²

Cabinet Material

Die cast aluminum

Die cast aluminum

Die cast aluminum

Die cast aluminum

Cabinet Size(mm)

600*337.5*31

600*337.5*31

600*337.5*31

600*337.5*31

Cabinet Weight

3.8kg/cabinet

3.8kg/cabinet

3.8kg/cabinet

3.8kg/cabinet

maintenance method

Front

Front

Front

Front

Support hanging or not

YES

YES

YES

YES

Best Viewing Distance

0.9m

1.2m

1.5m

1.8m

Best Viewing Angle

H:160° W:160°

H:160° W:160°

H:160° W:160°

H:160° W:160°

Max Power consumption

120 W/m²

120 W/m²

120 W/m²

120 W/m²

Average Power Consumption

40 W/m²

40 W/m²

40 W/m²

40 W/m²

Grey Scale

14--16 bits

14--24 bits

14--16 bits

14--16 bits

Color Temperature

6500~9000k

6500~9000k

6500~9000k

6500~9000k

Control Method

Synchronous

Synchronous

Synchronous

Synchronous

Refresh Rate

3840 Hz

3840 Hz

3840 Hz

3840 Hz

Brightness(cd/m²)

300-800

300-800

300-800

300-800

Operating Voltage

110V/220V

110V/220V

110V/220V

110V/220V

Working Humidity

10% - 90%

10% - 90%

10% - 90%

10% - 90%

Working Temperature

-20ºC - 65ºC

-20ºC - 65ºC

-20ºC - 65ºC

-20ºC - 65ºC

Protection Level

IP20

IP20

IP20

IP20


Durable HD SMD1515 Curtain Stage Background Led Screen 1.8m LED Panel
Durable HD SMD1515 Curtain Stage Background Led Screen 1.8m LED Panel



FAQ :


1 . Reply your inquiry in 24 working hours .


2 . Experienced staffs answer all your query in fluent English , Spanish , French , German etc .

3 . Customized design is available , OEM & ODM are welcomed .

4 . Exclusive and unique solution can be provided to our customer by our well - trained and professional
engineers and staffs .

5 . Special discount and protection of sales area provided to our distributor .

6 . Warmly welcome your visit in our company if available .

7 . Guidance service : We can guide on line if customers have questions about the installation and usage .
For large project , we provide your engineer a week free training , or if customer could bear the relevant cost ,
our engineer can go to customer ' s country for on-site guidance .

8 . Warranty period : 2 - 3 years after shipment .
