Product Details:
Place of Origin: ShenZhen, China
Brand Name: Longdaled
Certification: CE/ RoHs/ FCC/ CCC/ ISO9001/ ISO14001
Model Number: O-P4 P5 P6 P8 P10
Payment & Shipping Terms:
Minimum Order Quantity: 1 Sqm
Price: Usd899~Usd1399/Sqm ( price is negotiable )
Packaging Details: Flight case packing or Plywood case packing
Delivery Time: 15-18 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 5000sqm per month

Customized Outdoor LED Video Wall LED Displays Diecasting Aluminum Cabinets

Description
Model: 4mm-10mm Cabinet Size: 960*960mm
Module Size: 320 X 160mm Led Lamp: RGB 3IN1 KINGLIGHT
Brightness: ≥4500nits-7000nits Refresh Rate: 1920-3840hz
High Light:

Customized Outdoor LED Displays OEM

,

Diecasting Aluminum Outdoor LED Video Wall

,

4500nits Outdoor LED Video Wall

Customized Outdoor LED Video Wall Led Displays With Diecasting Aluminum Cabinets




Product Introduction



1 . High Definition, wonderful visual performance.

2 . High brightness ensures the spectators far from the screen can still enjoy what is shown, even under direct sunlight.

3 . High resolution could guarantee superior performance even with small screen size.





Specificatins



Pixel Pitch

4mm

Module Resolution

W80×H40dots

Module Size

320*160mm

Led Packing

2121/1921

IP Rate

65

LED composition

1R1G1B



Cabinet Specification

Cabinet Size

960*960mm

Module Qty

W3X H6= 18PCS

Physical Resolution

W240×H240dots

Power Consumption(MAX.)

600 W/m²

Power Consumption(AVE.)

200 W/m²

Cabinet Material

Iron Waterproof Cabinet

Physical Density

62500 dots/m²

Net Weight

28Kg



Customized Outdoor LED Video Wall LED Displays Diecasting Aluminum Cabinets 0




FAQ



1 . Strict quality control :
The quality of our display is excellent .

We use the materials of high quality suppliers in the world , strictly control the production process ,

and pass the multiple quality inspection to ensure that everyproduct is qualified .

2 . Quality guarantee :
All our LED display screens is more than 100,000 hours life span .

3 . Long warranty :
Two- year warranty , any quality problem during warranty time will be handled .

4 . Prompt & Professional service :
Any inquires will be replied within 24/7 hours and you'll get helpful suggestions from us .




Your questions


Q1 : LED display models are generally expressed in PX , such as P2 P3 P4.....P8, P10 , what does this mean ?
A : P1.25, P2, P3 P4.....P8,P10 means that the pixel pitch is 1.25mm, 2mm, 3mm 4mm....10mm,

which determines resolution of a display . Pixel pitch is smaller , led display resolution is higher .

Q2 : What pixel pitch should I choose on my display ?
A : Using the PX screen , it is determined mainly by the viewing distance , the size of the display screen ,

the desired effect and the customer budget .

Q3 : To order a display , What kind of information do I have to offer you ?
A : You should provide width / height of the display , the main use , the viewing distance , the scene photos ,

special requirements , then I can provide you with a detailed list of quotations .

Q4 : How to install ?
A : Free of charge to provide detailed steel structure drawings and installation guidance and wiring diagram ,

free remote debugging . We can also send our engineers to the site to guide the installation if needed .

Q5 : What about the lead time ?
A : Orders less than 50 square meter display , lead time is 15 working days .

Q6 : Can I order a sample ?
A : Yes , your sample orders are welcome , after checking our quality and service ,

we are confident that you will come back for your future orders .
