Product Details:
|
Lamp Size: | 1921 | Physical Resolution: | 32789 Dots/m² |
---|---|---|---|
Model: | P3.91mm | Cabinet Size: | 1000 X 500mm |
Refresh Rate: | 3840hz | Color: | RGB 3IN1 |
High Light: | Transparent Display Screen 1000x500mm,transparent screen for shop SMD1921,32789 dots /m2 glass video wall |
Transparente Display Screen High Transparency 3.91mm Glass Window Video Wall
Product Introduction :
1. Aviation plug and quick lock is used , bringing easier cables connection and quicker assembly of cabinets to save time ;
2. Low power consumption and fast heat dissipation with dual channel heat dissipation ;
3. Support a series of detection functions, for example detection of cables failure, detection whether the door of
cabinets closed or not fans speed monitoring , three - way voltage monitoring and temperature monitoring etc .
Specifications :
P3.9-7.8 Full Color LED Transparent Screen |
||||||||||
Part I Technicial Parameters |
||||||||||
Led Module Specification |
||||||||||
Item |
Specification |
|||||||||
Pixel Pitch |
3.9-7.8mm |
2.8-5.6mm |
7.8-7.8mm |
10.4-10.4mm |
||||||
Led Packing |
1921 |
1921 |
2020 |
1921 |
1921 |
2020 |
1921 |
1921 |
||
IP Rate |
43 |
|||||||||
IC |
2038 |
|||||||||
LED composition |
1R1G1B |
|||||||||
Cabinet Specification |
||||||||||
Cabinet Size |
1000*500mm |
1000*1000mm |
||||||||
Physical Resolution |
W256×H64dots |
W352*H88dots |
W128*H64dots |
W96*H96dots |
||||||
Power Consumption(MAX.) |
800 W/m2 |
600W/m2 |
400W/m2 |
800 W/m2 |
800 W/m2 |
600W/m2 |
800 W/m2 |
|||
Power Consumption(AVE.) |
220 W/m2 |
200W/m2 |
180W/m2 |
220 W/m2 |
220 W/m2 |
200W/m2 |
220 W/m2 |
|||
Cabinet Material |
Die-casting Aluminum |
Sectional material |
||||||||
Physical Density |
32873 dots/m2 |
63775 dots/m2 |
16436 dots/m2 |
9245 dots/m2 |
||||||
Net Weight |
6Kg |
10Kg |
||||||||
Screen Specification |
||||||||||
Brightness |
5000cd/m2 |
3500cd/m2 |
1000cd/m2 |
5000cd/m2 |
1200cd/m2 |
5000cd/m2 |
3500cd/m2 |
5000cd/m2 |
||
Colors |
281 trillion |
|||||||||
Brightness Control |
Software 256 level adjustable |
|||||||||
Gray Level |
14 |
|||||||||
View Distance |
5~12m |
|||||||||
Refresh Rate |
≥3840Hz |
|||||||||
Drive Mode |
1/8s |
1/16s |
1/11s |
1/4s |
1/2s |
|||||
Life Span |
100,000h |
|||||||||
MTBF |
1000h |
|||||||||
Control mode |
Synchronous control or Asynchronous control |
|||||||||
Frame Frequency |
≥60Hz |
|||||||||
Certification |
CE/ROHS/FCC/CCC/ISO9001/ISO14001 |
|||||||||
Operation Temperature |
-20℃ ~ +45℃ |
|||||||||
Operation Humidity |
10%~95% |
FAQ :
Q1. Could I get a sample order of led display?
A: Yes, welcome to your sample order to check the quality.
Q2: Could we print our own logo on led display products?
A: Of course. Please let us know all the details soon before production.
Q3: Do you offer guarantee for the led display products?
A: Yes, we offer one year warranty for our products.
Q4: Whether to provide technical training (installation training and use training)?
A: Yes, we offer full service, Including pre-sale, sale, after-sales service, you can rest assured to buy.
