16.7M Colors Airport Small Pixel Led Display NOVA STAR High Resolution MBI5124 IC

16.7M Colors Airport Small Pixel Led Display NOVA STAR High Resolution MBI5124 IC
16.7M Colors Airport Small Pixel Led Display NOVA STAR High Resolution MBI5124 IC 16.7M Colors Airport Small Pixel Led Display NOVA STAR High Resolution MBI5124 IC 16.7M Colors Airport Small Pixel Led Display NOVA STAR High Resolution MBI5124 IC 16.7M Colors Airport Small Pixel Led Display NOVA STAR High Resolution MBI5124 IC

Large Image :  16.7M Colors Airport Small Pixel Led Display NOVA STAR High Resolution MBI5124 IC

Product Details:
Place of Origin: ShenZhen
Brand Name: Longda LED
Certification: CE / RoHs / FCC / CCC / ISO9001 / ISO14001
Model Number: P1.86
Payment & Shipping Terms:
Minimum Order Quantity: 1 Sqm
Price: Usd899 ~ Usd1399 / Sqm ( price is negotiable )
Packaging Details: Flight case packing or Plywood case packing
Delivery Time: 15 - 18 days
Payment Terms: L / C , T / T , Western Union , MoneyGram
Supply Ability: 5000sqm per month

16.7M Colors Airport Small Pixel Led Display NOVA STAR High Resolution MBI5124 IC

Description
Model Pixel: 1.86mm Module Resolution: 172 X 86 Dots
Cabinet Size: 640 * 480mm Led Lamp: KINGLIGHT 1515
Scan: 43S Life Span: 100000h
High Light:

Small Pixel Led Display NOVA STAR

,

16.7M colors airport led display

,

High resolution Led Display MBI5124 IC

Small Pixle Led Screen RGB3IN1 P1.86 640 X 480mm Die-Casting Aluminum Cabinet





Functions and Advantages :



1 . High refresh rate : With NOVA STAR control system , no scanning line when photographed ;
2 . High gray level : 256 RGB each ,display 16.7M colors , vivid and perfect video effect ;
3 . High resolution : The most apparent features of the new generation of LED display ;
4 . Good color uniformity : With brand Lamp Nationstar and high refresh MBI5124 IC .





Specifications :



Indoor P1.86 LED Screen

Part I Technicial Parameters

Led Module Specification

NO.

Item

Specification

1

Pixel Pitch

1.86mm

2

Module Resolution

W172×H86dots

3

Module Size

320*160mm

4

Led Packing

1515

5

IP Rate

43

6

IC

6363

2065

7

LED composition

1R1G1B

Cabinet Specification

1

Cabinet Size

640*480mm

2

Module Qty

W2X H3 =6PCS

3

Physical Resolution

W344×H258dots

4

Power Consumption(MAX.)

200 W/m2

5

Power Consumption(AVE.)

120W/m2

140W/m2

6

Cabinet Material

Die-casting Aluminum

7

Physical Density

288906 dots/m2

8

Net Weight

7.5Kg

8Kg

Screen Specification

1

Brightness

≥600cd/m2

≥670cd/m2

2

Colors

16.7 trillion

3

Brightness Control

Software 256 level adjustable

4

Gray Level

14

5

View Distance

1.9-15m

6

Refresh Rate

≥1920~3840Hz

≥3840Hz

7

Drive Mode

1/43s

1/57s

8

Life Span

100,000h

9

MTBF

1000h

10

Control mode

Synchronous control or Asynchronous control

11

Frame Frequency

≥60Hz

12

Certification

CE/ROHS/FCC/CCC/ISO9001/ISO14001

13

Operation Temperature

-20℃ ~ +45℃

14

Operation Humidity

10%~95%



16.7M Colors Airport Small Pixel Led Display NOVA STAR High Resolution MBI5124 IC 0





FAQ :



Question1 : How can I trust your LONGDA LED factory ?

Answer : Yes , when you talk with us now , we are here . We do led since 2009 , it is over 12 years .

In the past 8 years , we develop so well . Tomorrow and future , we will largely expand our LED market, you will see it .
Welcome to try our LED sample quality .
We do have100% confidence in our LED product .

Question2 : If I need led very urgently , how fast can you finish the goods ?

Answer : How fast you want ?Three days ?One week ? Definite shipping date ?
We produce LED everyday .We have some led modules in stock .
Put the most urgent and important order at the first place .
You are important to us . Surely to establish first-time good relationship .
We do must finish it at FAST ROCKET TIME.

Question3 : Is it easy to install this led display ?

Answer : If you are new to LED ,we will help you to know led from ZERO to Professional .
We have installation manual book and professional engineering team to guide you .
To help you better understand LED is to make us get your earlier trust .
If you knew LED before,we can learn from each other.
We could be Future Shaking-hands Partners .
Our engineering team remote help is ready for you 24-hours .
