Product Details:
|
Model: | 4.81mm | Cabinet Size: | 500 X 1000mm |
---|---|---|---|
Led Lamp: | KINGLIGHT 2020 | IP Rate: | 65 |
Net Weight: | 6.1Kg | Gray Level: | 16 |
Highlight: | Longda Wedding Led Screen,KINGLIGHT 2020 led video display screen,indoor led video wall smd2020 |
Wedding Led Screen P4.81 Outdoor Rental Floor LED Video Display Screen
Product Introduction :
1 . Ultra slim and lightweight : 6.1kg per cabinet weight ( 500 x 1000mm) , greatly saves transportation
costs and labor costs ;
2 . Rental die - casting aluminum structure : rock solid , not easy to deform ;
3 . Seamless splicing : give you a better visual experience ;
4 . Quick lock system , easy installation : quick installation , complete the installation in a few seconds .
Specifications :
Physical Pitch |
2.97mm |
3.91mm |
4.81mm |
Pixel Configuration |
SMD2121 |
SMD2121 |
SMD2121 |
Pixel Density |
112,896 pixels/sqm |
65,536 pixels/sqm |
43,264 pixels/sqm |
Module Dimension (W*H)(mm) |
250*250 |
250*250 |
250*250 |
Panel Dimension(mm) |
500*500*80/500*1000*75 |
500*500*80/500*1000*75 |
500*500*80/500*1000*75 |
Physical Resolution of Panel(W*H) |
168*168/168*336 |
128*128/128*256 |
104*104/104*208 |
Panel Material |
Die-Casting Aluminum |
Die-Casting Aluminum |
Die-Casting Aluminum |
Single Cabinet Weight |
8/14 kg/panel |
8/14 kg/panel |
8/14 kg/panel |
Processing |
16 bit |
16 bit |
16 bit |
Contrast Ratio |
4,000:1 |
4,000:1 |
4,000:1 |
Average Power Consumption |
64/128 W/panel |
64/128 W/panel |
64/128 W/panel |
Max Power Consumption |
192/384 W/panel |
192/384 W/panel |
192/384 W/panel |
Refresh Rate |
>1,920 Hz |
>1,920 Hz |
>1,920 Hz |
Brightness |
>1,200 nits |
>1,200 nits |
>1,200 nits |
Horizontal Viewing Angle |
160° |
160° |
160° |
Vertical Viewing Angle |
140° |
140° |
140° |
Servicing |
Front/Rear |
Front/Rear |
Front/Rear |
IP Rating (Front/Rear) |
IP40/IP21 |
IP40/IP21 |
IP40/IP21 |
Our Services & Strength :
1. Your inquiry about our products or the price will be replied within 24 hours !
2 . We provide 2 years for warranty and lifelong maintaining , you will appreciate our warm after - sale service .
3 . We will delivery goods as you demand , you can choose the cheaper and more convenient way !
4 . Apart from the Outdoor LED Display , Visionled also can offer you LED Pharmacy Cross Display ,
LED Flexible Display , Indoor LED Display , LED Gas Price Signs , Indoor / outdoor LED Signs .
