Product Details:
|
| Panel Resolution: | 32 X 32 Dots | Video Dimension: | 576 * 576mm |
|---|---|---|---|
| Gray Level: | 14 | IP Rate: | 65 |
| Emitting Color: | Full Color RGB | Lamp Type: | 3535 |
| High Light: | IP65 p6 led wall,columns p6 smd outdoor module,p6 outdoor led screen animation |
||
Led Stage Backdrop Screen Aluminum Hanging LED Screen Truss Display Outdoor Events P6
Functions and Advantages :
1 . LED advertisements with strong visual impact , large size , dynamic effect and sound and picture integration
can comprehensively stimulate the audience's senses and effectively convey information to guide consumption ;
2 . Outdoor LED screens with wide coverage are generally installed in shopping malls and other areas with
concentrated pedestrian flow . Through frequent communication with user groups , consumers' strong desire to
buy is stimulated and brand awareness is improved ;
3 . Long release period outdoor LED advertisements can be played around the clock .
It is easier for the audience to see , can better guide the potential customer group , so that businesses with less
cost to achieve better publicity effect ;
4. Outdoor LED advertisements with low audience aversion can broadcast programs to more audiences in a real
and timely manner through live broadcasting technology .
Including special topics , columns , variety shows , animation , radio plays , TV plays , etc , rich in content ,
to avoid the advertising audience consciously and actively avoid the contact barriers .
Specifications :
|
Outdoor P6 LED Screen |
|||||
|
Part I Technicial Parameters |
|||||
|
Led Module Specification |
|||||
|
NO. |
Item |
Specification |
|||
|
1 |
Pixel Pitch |
6mm |
|||
|
2 |
Module Resolution |
W32×H32dots |
|||
|
3 |
Module Size |
192*192mm |
|||
|
4 |
Led Packing |
3535 |
3528 |
||
|
5 |
IP Rate |
65 |
|||
|
6 |
IC |
Constant current IC |
5124 |
||
|
7 |
LED composition |
1R1G1B |
|||
|
Cabinet Specification |
|||||
|
1 |
Cabinet Size |
576*576mm |
960*960mm |
||
|
2 |
Module Qty |
W3X H3 =9PCS |
W5X H5 =25PCS |
||
|
3 |
Physical Resolution |
W96×H96dots |
W160×H160dots |
||
|
4 |
Power Consumption(MAX.) |
600 W/m2 |
|||
|
5 |
Power Consumption(AVE.) |
230 W/m2 |
300 W/m2 |
||
|
6 |
Cabinet Material |
Die-casting Aluminum |
|||
|
7 |
Physical Density |
27777 dots/m2 |
|||
|
8 |
Net Weight |
7.5Kg |
7.7Kg |
||
|
Screen Specification |
|||||
|
1 |
Brightness |
5500cd/m2 |
1000cd/m2 |
||
|
2 |
Colors |
16.7 trillion |
|||
|
3 |
Brightness Control |
Software 256 level adjustable |
|||
|
4 |
Gray Level |
14 |
|||
|
5 |
View Distance |
6～50m |
6~150m |
||
|
6 |
Refresh Rate |
≥1200~1920Hz |
≥960Hz |
||
|
7 |
Drive Mode |
1/8s |
1/16s |
||
|
8 |
Life Span |
100,000h |
|||
|
9 |
MTBF |
1000h |
|||
|
10 |
Control mode |
Synchronous control or Asynchronous control |
|||
|
11 |
Frame Frequency |
≥60Hz |
|||
|
12 |
Certification |
CE/ROHS/FCC/CCC/ISO9001/ISO14001 |
|||
|
13 |
Operation Temperature |
-20℃ ～ +45℃ |
|||
|
14 |
Operation Humidity |
10%～95% |
|||
FAQ :
|
Question1 : How can I trust your LONGDA LED factory ? |
|
Answer : Yes , when you talk with us now , we are here . We do led since 2009 , it is over 12 years . In the past 8 years , we develop so well . Tomorrow and future , we will largely expand our LED market, you will see it . |
|
Question2 : If I need led very urgently , how fast can you finish the goods ? |
|
Answer : How fast you want ? Three days ? One week ? Definite shipping date ? |
|
Question3 : Is it easy to install this led display ? |
|
Answer : If you are new to LED , we will help you to know led from ZERO to Professional . |
