Home ProductsTransparent Glass LED Screen

P10.4mm 50*12.5cm Transparent Glass LED Screen Grid Window Display 1000cd/ M²

Certification
China Shenzhen Longdaled Co.,Ltd certification
China Shenzhen Longdaled Co.,Ltd certification
I'm Online Chat Now

P10.4mm 50*12.5cm Transparent Glass LED Screen Grid Window Display 1000cd/ M²

P10.4mm 50*12.5cm Transparent Glass LED Screen Grid Window Display 1000cd/ M²
P10.4mm 50*12.5cm Transparent Glass LED Screen Grid Window Display 1000cd/ M² P10.4mm 50*12.5cm Transparent Glass LED Screen Grid Window Display 1000cd/ M² P10.4mm 50*12.5cm Transparent Glass LED Screen Grid Window Display 1000cd/ M² P10.4mm 50*12.5cm Transparent Glass LED Screen Grid Window Display 1000cd/ M²

Large Image :  P10.4mm 50*12.5cm Transparent Glass LED Screen Grid Window Display 1000cd/ M²

Product Details:
Place of Origin: ShenZhen
Brand Name: Longda LED
Certification: CE / RoHs / FCC / CCC / ISO9001 / ISO14001
Model Number: Transparent - P3.9
Payment & Shipping Terms:
Minimum Order Quantity: 1 Sqm
Price: Usd599 ~ Usd1099 / Sqm ( price is negotiable )
Packaging Details: Flight case packing or Plywood case packing
Delivery Time: 15 - 18 days
Payment Terms: L / C , T / T , Western Union , MoneyGram
Supply Ability: 5000sqm per month

P10.4mm 50*12.5cm Transparent Glass LED Screen Grid Window Display 1000cd/ M²

Description
Product Name: Transparent Glass Window Led Screen Usage: Chain Store / Bank / Jewelry Shop
Light Source: LED Pixel Pitch: 3.9mm
Brightness: ≥5000nits Frame Frequency: 3840hz
High Light:

50*12.5cm Transparent Glass LED Screen

,

p10.4mm transparent window display

,

transparent led grid screen 1000cd/ m2

Transparent Glass Led Screen High Brightness Indoor Transparent LED Screens For Glass Wall / Shop Window / 4s Store





Advantages



1 . The lamp bead has a high penetration rate of 70% - 95% , which ensures the original lighting and perspective

function of the glass curtain wall , does not take up space, light weight ;



2 . The thickness of the main board is only 10mm , and the weight of the display screen is only 15Kg / ㎡ .

It is directly fixed on the glass curtain wall without changing the structure of the building .



3 . No steel frame structure , saving a lot of installation and maintenance costs .

Directly fixed on the glass curtain wall , without any steel structure , save a lot of cost .



4 . The unique display effect because the display background is transparent , can make the advertising picture

give people the feeling of suspension on the glass curtain wall , with good advertising effect and artistic effect .



5 . Easy and fast maintenance of indoor maintenance , both fast and safe , save manpower and material resources .



6 . Energy saving and environmental protection do not need the traditional refrigeration system and

air conditioning heat dissipation , compared with ordinary LED display energy-saving more than 30% .





Applications



Transparent glass curtain wall p10.4 gain a good space visual effect indoor , its a new fashion trade

for window display especially some luxury store , brand store , chain store , shopping mall , exhibition center ,

airport , metro station , automobile 4S shop , jewelry store , bank , etc . transparent is the most high definition one ,

high transparency and elegant , will be popular in the market soon .



P10.4mm 50*12.5cm Transparent Glass LED Screen Grid Window Display 1000cd/ M² 0





Technical parameter



P3.9-7.8 Full Color LED Transparent Screen

Part I Technicial Parameters

Led Module Specification

NO.

Item

Specification

1

Pixel Pitch

3.9-7.8mm

2

Module Resolution

W128×H16dots

3

Module Size

500*125mm

4

Led Packing

1921

1921

2020

5

IP Rate

43

6

IC

2038

7

LED composition

1R1G1B

Cabinet Specification

1

Cabinet Size

1000*500mm

2

Module Qty

W2X H 4 =8PCS

3

Physical Resolution

W256×H64dots

4

Power Consumption(MAX.)

800 W/m2

600W/m2

400W/m2

5

Power Consumption(AVE.)

220 W/m2

200W/m2

180W/m2

6

Cabinet Material

Die-casting Aluminum

7

Physical Density

32873 dots/m2

8

Net Weight

6Kg

Screen Specification

1

Brightness

5000cd/m2

3500cd/m2

1000cd/m2

2

Colors

281 trillion

3

Brightness Control

Software 256 level adjustable

4

Gray Level

14

5

View Distance

5~12m

6

Refresh Rate

≥3840Hz

7

Drive Mode

1/8s

1/16s

8

Life Span

100,000h

9

MTBF

1000h

10

Control mode

Synchronous control or Asynchronous control

11

Frame Frequency

≥60Hz

12

Certification

CE/ROHS/FCC/CCC/ISO9001/ISO14001

13

Operation Temperature

-20℃ ~ +45℃

14

Operation Humidity

10%~95%



P10.4mm 50*12.5cm Transparent Glass LED Screen Grid Window Display 1000cd/ M² 1





Our service

Pre-sale service:

1. Inquiries will be replied within 24 hours.
2. Market research and forecast for customer.
3. Provide unique and professional solutions based on customer's requirement.
4. Data sheet and samples offered.
5. Other required services such as special packing design, factory visiting and so on.


In-sale service:

1. Tracking producing procedures all the time.
2. Provide photos and videos as per customer's requirement during production.
3. Free spare parts provided.


After-sale service:

1. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
2. Warranty: 1year
3. Free technician training.
4. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD an
d so on.




FAQ


Q1 : How does your factory do regarding quality control ?
Quality is priority . We always attach great importance to quality controlling from the very beginning to the very end .
We focus on every detail , our factory has gained ISO9001 , ISO14001 , CE , RoHS , FCC certifications .

Q2 : What is your MOQ ?
Any quantity is acceptable for your order . And the price is negotiable for large quantity .

Q3 : When will you make the delivery ?
We can make the delivery within 3 - 5 working days for the led modules and 15 - 18 days for the led finished screen according to the size and quantities of your order .

Q4 : What technical supports can you offer ?
We provide all kinds of technology trainings for free , including the operation and maintenance
training of the LED screens in our factory . we can send an engineer team to the country of the customer to instruct the installation .

Q5 : How long is the warranty ?
The standard warranty is 1 year . It could be longer upon request .


Q6 : Do you provide any free spare parts in each order ?
Yes , a certain amount of spare parts will be provided for free , spare parts including module , power cable , signal cable , LED lamp , IC , mask , power supply , receiving card , etc .
