Tri-fold LED Poster Screen - Plug and Play Removable Advertising Display
The tri-fold poster screen is a portable, three-panel digital display designed to capture attention in any retail environment. Each folding panel features high-brightness, full-color LED modules that deliver vibrant, seamless visuals. The foldable frame enables single-person setup and takedown in seconds without tools.
Technical Specifications
| Item |
P1.25 |
P1.538 |
P1.86 |
P2 |
P2.5 |
P3 |
| Pixel Pitch |
1.25mm |
1.538mm |
1.86mm |
2mm |
2.5mm |
3mm |
| Module Size |
320*160mm |
320*160mm |
320*160mm |
320*160mm |
320*160mm |
192*192mm |
| Display Resolution |
1024*1536 |
832*1248 |
688*1044 |
640*960 |
512*768 |
426*640 |
| LED Encapsulation |
SMD1010 |
SMD1212 |
SMD1515 |
SMD1515 |
SMD2121 |
SMD2121 |
| Pixel Density |
1,572,864 |
1,038,336 |
718,272 |
614,400 |
393,216 |
272,640 |
| Brightness |
500-1000cd |
2700cd |
2700cd |
2700cd |
2700cd |
2700cd |
| Drive Mode |
1/64 Scan |
1/52 Scan |
1/43 Scan |
1/40 Scan |
1/32 Scan |
1/32 Scan |
| Max Consumption (W/screen) |
1200 |
1100 |
960 |
900 |
800 |
960 |
| Average Consumption (W/screen) |
480 |
440 |
380 |
360 |
340 |
320 |
General Specifications
Display Size (Unfolded): 1316mm * 2000mm * 59mm
Display Size (Folded): 658mm * 2000mm * 128mm
Cabinet Material: Die-casting aluminum (or sheet metal)
Frame Color: Black (default)
Weight: 55 kg/pcs
Optimum Viewing Angle: 160° (Vertical), 160° (Horizontal)
Gray Scale: ≥14 bit
Refresh Frequency: 1920Hz/3840Hz
Contrast: 5000:1
Operating Power: AC110V~240V, 50~60Hz
Display Mode: Synchronous control, Asynchronous control
Control Mode: WiFi, Network
Support Video Files: MPEG/H.264
Operating Temperature: -30℃ to +70℃
Lifespan: 100,000 hours
Key Advantages
-
Eye-Catching Dynamic Display – High-brightness LED panels play video, animation, and scrolling content, capturing far more attention than static printed posters.
-
Ultra-Portable Tri-fold Design – Folds into three slim sections for compact transport and storage, easily moving into any venue without bulky rigging.
-
Tool-Free, Fast Deployment – Opens and powers up in minutes; the tri-fold structure provides a stable freestanding base right out of the case.
-
Wrap-Around Visual Impact – Three connected LED panels create a wide, immersive viewing angle that surrounds audiences from multiple directions.
-
Real-Time, Instantly Updatable Content – Change promotions, prices, or campaigns anytime via USB, Wi-Fi, or cloud control – no reprinting, no downtime.
Product Features
-
Multiple Input Ports – Equipped with USB, HDMI, and network interfaces for easy content loading and integration.
-
Energy-Saving Power Supply – Low power consumption with an efficient built-in power system.
-
Tool-Free Assembly – Quick-lock folding mechanism enables fast setup and teardown without tools.
Packaging & Delivery
Selling Units: Single item
Case Quantity: 1pcs (or 2pcs or 3pcs per wooden case or flight case)
Package Size (1pcs): 110.00cm * 73.00cm * 110.00cm
Weight: Base style: 36kg (640) / 54kg (960) – Not including suite and power supply
Material: Die-casting aluminum (or sheet metal)
Installation: Bracket or base installation
Color: Grey
